Bharaj Machinery: Rubber Moulding Machine : ASTM Standards

Our design department, keeping in view the latest trend, designed machinery with the help of CADD system to achieve better accuracy & precision.
Equipped with high speed hydraulic with an optional hydraulic proportional system which is offered only by "BHARAJ".
Equipped with automatic mould handling system which are very convenient for two plates, three plates or four plates mould. Which can be opened inside or outside the press. With auto demoulding system as optional.
Shorter curing times resulting in high production. Very simple & sturdy structure for easy maintenance & efficient working.

MODEL NO.	BCP-75	BCP-100	BCP-150	BCP-200	BCP-250	BCP-300	BCP-350	BCP-400	BCP-500	BCP-600
PLATEN SIZE (MM)	360X360	410X410	460X460	510X510	610X610	660X660	760X760	800X850	1000X1000	1200X1200
MACHINE TONNAGE	75	100	150	200	250	300	350	400	500	600
RAM SIZE DIA (MM)	220 MM	250 MM	300 MM	350 MM	400 MM	450 MM	500 MM	550 MM	600 MM	600 MM
DAYLITE GAP	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-950 MM	600-950 MM
MAIN RAM STROKE	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-950 MM	600-950 MM
MAIN MOTOR	5 HP	5 HP	5 HP	7.5 HP	10 HP	10 HP	15 HP	15 HP	20 HP	20 HP

Our design department keeping in view the latest trend, designs machinery with the help of cadd systems to achieve better accuracy & precision.
No air entrapment while moulding.
Our vacuum press is provided with the most hi-tech vacuum system which provides vacuum suction of 650 700 hg/2 sec, which ensures zero air entrapment.
Equipped with high speed hydraulic unit with an optional hydraulic proportional system which is offered only by "Bharaj".

Equipped with automatic mould handling system which are very convenient for two plates, three plates or four plates mould. Which can be opened inside or outside the press. With auto demoulding system as optional.
Shorter curing times resulting in high production.
Very simple & sturdy structure for easy maintenance & efficient working.

Model No.	BVP-75	BVP-100	BVP-150	BVP-200	BVP-250	BVP-300	BVP-350	BVP-400	BVP-500
PLATEN SIZE (MM)	360x360	410x410	460x460	510x510	610x610	660x660	760x760	800x850	1000x1000
MACHINE TONNAGE	75	100	150	200	250	300	350	400	500
RAM SIZE DIA (MM)	220 MM	250 MM	300 MM	350 MM	400 MM	450 MM	500 MM	550 MM	600 MM
DAYLITE GAP	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-900 MM
MAN MOTOR	5 HP	5 HP	5 HP	7.5 HP	10 HP	10 HP	15 HP	15 HP	20 HP
MAIN RAM STROKE	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM

Our design department, keeping in view the latest trend, designed machinery with the help of CADD system to achieve better accuracy & precision.
Equipped with high speed hydraulic with an optional hydraulic proportional system which is offered only by "Bharaj".
Equipped with automatic mould handling system which are very convenient for two plates, three plates or four plates mould. Which can be opened inside or outside the press. With auto demoulding system as optional.
Shorter curing times resulting in high production. Very simple & sturdy structure for easy maintenance & efficient working.

MODEL NO.	BCP-75	BCP-100	BCP-150	BCP-200	BCP-250	BCP-300	BCP-350	BCP-400	BCP-500	BCP-600
PLATEN SIZE (MM)	360X360	410X410	460X460	510X510	610X610	660X660	760X760	800X850	1000X1000	1200X1200
MACHINE TONNAGE	75	100	150	200	250	300	350	400	500	600
RAM SIZE DIA (MM)	220 MM	250 MM	300 MM	350 MM	400 MM	450 MM	500 MM	550 MM	600 MM	600 MM
DAYLITE GAP	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-950 MM	600-950 MM
MAIN RAM STROKE	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-950 MM	600-950 MM
MAIN MOTOR	5 HP	5 HP	5 HP	7.5 HP	10 HP	10 HP	15 HP	15 HP	20 HP	20 HP

Our design department keeping in view the latest trend, designs machinery with the help of cadd systems to achieve better accuracy & precision.
No air entrapment while moulding.
Our vacuum press is provided with the most hi-tech vacuum system which provides vacuum suction of 650 700 hg/2 sec, which ensures zero air entrapment.
Equipped with high speed hydraulic unit with an optional hydraulic proportional system which is offered only by "Bharaj".

Equipped with automatic mould handling system which are very convenient for two plates, three plates or four plates mould. Which can be opened inside or outside the press. With auto demoulding system as optional.
Shorter curing times resulting in high production.
Very simple & sturdy structure for easy maintenance & efficient working.

Model No.	BVP-75	BVP-100	BVP-150	BVP-200	BVP-250	BVP-300	BVP-350	BVP-400	BVP-500
PLATEN SIZE (MM)	360x360	410x410	460x460	510x510	610x610	660x660	760x760	800x850	1000x1000
MACHINE TONNAGE	75	100	150	200	250	300	350	400	500
RAM SIZE DIA (MM)	220 MM	250 MM	300 MM	350 MM	400 MM	450 MM	500 MM	550 MM	600 MM
DAYLITE GAP	500 MM	500 MM	500 MM	400-500 MM	400-500 MM	400-500 MM	400-500 MM	500-800 MM	500-900 MM
MAN MOTOR	5 HP	5 HP	5 HP	7.5 HP	10 HP	10 HP	15 HP	15 HP	20 HP
MAIN RAM STROKE	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM	500 MM
